Garage Buildings

Bridge Timber Stables are not only designers and installers for equestrian buildings, we are also able to supply and fit other types of outdoor buildings, such as garages and sheds, without going through the planning process.

We build our garage buildings to the same high standards as our equestrian buildings. As all our buildings are bespoke, we are able to build and manufacture to your requirements.

Available in single/double/treble garages – but again as all our buildings are bespoke, we build to your needs.

Shiplap Cladding

Top grade redwood shiplap cladding 16mm x 150mm, fixed with 50mm sheradised ring shank nails

Featheredge Cladding

Pressure treated ex 19mm x 150mm rough sawn featheredge horizontal cladding

Cladding Colours

Standard colours available are natural, light brown, dark brown or black.
Other colours available on request.

Frame work

The frameworks are manufactured with kiln dried timber, 47mm x75mm. All timber is regularised and strength graded for structural use to C16-C24

Kickboarding

All stables are kickboarded as standard to a height of 1.2m high with exterior grade 12mm Spruce plywood – multiple 5 layered, for structural integrity.

Roof

Black Onduline roof with galvanised ridge. Comes with a 15 year manufacturers warranty and has been wind tested up to 120mph. Also available in green, brown or red.

Standard roof pitch is 25 degrees

Purlins 100mm x 47mm, x 125mm x 47mm, 100mm x 100mm. Fitted to Onduline specification

Doors

Doors are manufactured from 125mm x 25mm tongue, groove and v-jointed timber, ledged and braced.

Both top and bottom doors are lined with exterior grade plywood to give an overall thickness of 50mm

Stable door size 1.1 wide x 2.1 high. Top door 0.8m high. Bottom door height 1.3m

Bottom doors are furnished with 1 x strong anti-chew strip, 1 x heavy duty kick-over latch and 1 x 225mm brenton bolt, 1 x 150mm cabin hook and 1 pair of 600mm heavy duty tee hinges.

Top doors have 1 x 100mm oval pad bolt, 1 x 150mm cabin hook, 1 pair of 600mm heavy duty tee hinges.

All door furniture is fully galvanised.
